WITT (Windows I2C Test Tool)

· Helps validate Windows I2C controller drivers with a software suite provided by Microsoft.

· Utilizes a Cypress EZ-USB FX2 USB Controller

                          (Chip is USB-IF Certified - TID # 40460272)

· Utilizes 4 NXP PCA9665 I2C controllers to provide multiple slave devices on a 3.3 volt I2C bus.

· I2C Connector is pin compatible with Total Phase Aardvark.

· 4 GPIO lines at 3.3 volts.

· USB bus powered device.







More information about I2C on Windows can be found at the Simple Peripheral Bus page.

Note: it’s recommended that new purchases that MITT + I2C Adapter be used instead.
