MUTT (Microsoft USB Test Tool)

· Cypress EZ-USB FX2LP 8051 Microcontroller

Uses Cypress EZ-USB FX2LP IC (Chip is USB-IF Certified - TID # 40460272)

· 16 KBytes of On-Chip Code/Data RAM

· Four Programmable BULK, INTERRUPT, and ISOCHRONOUS Endpoints—Buffering options: double, triple, and quad

· Two additional programmable (BULK/INTERRUPT) 64 byte endpoints; one IN, one OUT.

· Low power USB bus powered device.

· Onboard +3.3V Voltage Regulator

· EEPROM 64Kb I2C

· Tiny only 2.2 x 0.64 inches
